Start with a surveyed fence line
A total run length is enough for an early budget, but not for a production order. Mark corners, changes in direction, walls, gate openings, utilities, and finished-grade levels on a plan. Distinguish surveyed dimensions from estimates, and identify which contractor will verify the final setout before EONE fabricates special panels.
The nominal 2400 mm width shown on several EONE steel panels is not automatically the post-center spacing. Connections, clearances, and end details affect the actual bay. Record panel width, clear opening, and post centers as separate dimensions so the purchasing team and installer are working from the same geometry.
Resolve slopes without forcing the panel
Decide whether the visual line should step at posts or follow the grade through purpose-designed sloped panels. A rackable system is another possibility only when its joints are specifically designed and documented for that movement. Do not twist an ordinary rigid welded panel to make it fit a slope.
Some manufacturers offer their own terrain-following systems; Ameristar's Montage residential range illustrates that terrain accommodation is a product-system feature. It is not a capability to assume for an EONE catalog panel. Show grade breaks, required clearances, and any sloping rail geometry on the project drawing for review.
Choose the barrier role and gate interfaces
A landscape boundary, pool enclosure, and protective guard have different requirements. For pool work, the CPSC barrier guide is a useful starting reference, while the responsible local authority determines applicable requirements. A familiar nominal height does not establish compliance for the complete assembly.
- Confirm fence height, top style, opening geometry, and the consequences of stepped bottom gaps.
- Schedule gate clear openings, operating direction, travel clearance, hinges, latches, and stops.
- Have the responsible designer review posts, foundations, connections, soil or substrate, and exposure.
- Separate any automated-gate safety and operator review from the decorative fence purchase.
Align finish and component schedules
Record the selected rail and picket sections, post types, bracket references, cap style, and hardware finish. Include any transition from a low flat-top run to a taller section. For replacement work, measure the existing rail elevations rather than relying on a photograph; a small mismatch becomes conspicuous along a long horizontal line.
Approve a coating sample and written finish requirements, including pretreatment, corrosion-protection route, color, gloss, and repair limits. Ask EONE to review custom widths, end connections, or altered rail positions as a coordinated package. Do not assume field drilling or cutting is acceptable after coating.
Plan receiving as part of selection
Door-to-door or site delivery can be arranged under the agreed quotation. Provide access restrictions, receiving hours, turning space, unloading equipment, and a safe staging location. Confirm bundle dimensions and weights before dispatch. Installation, crane service, duties, foundations, and every accessory are not automatically included; the written scope identifies each responsibility.
At receipt, compare labels and quantities with the approved bay schedule before distributing panels around the property. Check visible damage and critical dimensions early. Use the steel fence collection as a starting point, then submit the project package and arrange samples for appearance and connection review where needed.
