Measure more than the driveway width
For a sliding gate, the most useful survey combines the clear vehicle opening with the entire side travel area. Show the direction of travel on a plan, using a labeled street-side or property-side viewpoint. Include boundary walls, trees, services, parking, and any pedestrian route beside the gate. Use this evidence when choosing from EONE's Sliding Driveway Gates collection.
Do not equate opening width with overall gate length or required run-back. Support and end details can extend beyond the visible closing panel. Ask for an approval drawing that identifies all three dimensions and shows the fully open position.
Choose a support arrangement that suits the site
Confirm whether the proposal uses ground track or a cantilever structure. TYMETAL's manufacturer guidance explains how cantilever gates avoid a roadway track but require a counterbalanced support arrangement. Treat that as a system comparison, not a universal sizing formula or an assurance that a particular EONE pattern is already available in either format.
Provide surveyed levels across the opening and along the run-back. Road crown, drainage channels, paving transitions, and seasonal debris deserve review before hardware selection. A rigid sliding leaf cannot simply follow uneven ground. Do not resolve a slope by arbitrarily tilting a powered travel path; have the gate designer and installer establish suitable geometry.
- Identify support-post locations, foundation responsibilities, and underground service constraints.
- Show guide, receiving, and stop interfaces in the proposed system drawing.
- Keep the travel zone clear of storage, planting, and public circulation conflicts.
- Include access for inspection, adjustment, and replacement of the selected hardware.
Coordinate material, pattern, and powered operation
Confirm metal specification, panel construction, finish, and the expected finished gate mass before selecting an operator. LiftMaster's buyer guidance identifies gate type, size, weight, and operating frequency as selection inputs. An operator choice should come from the qualified installer using the actual proposed assembly, not the appearance of a similar gate online.
Discuss how the decorative pattern affects the project brief, including privacy and site exposure. Any wind or structural assessment belongs to the project professionals; a more open pattern is not a substitute for that assessment. Show approved operator mounting interfaces before production rather than leaving them for unplanned field modifications.
Request a documented safety review covering the moving gate, adjacent fixed objects, pedestrian separation, protective devices, controls, and commissioning. ASTM F2200 is relevant to automated vehicular construction. Ask the responsible reviewer to identify the applicable requirements and supporting evidence for the proposed gate, operator, and installed system before order approval.
Release a defined package
List the leaf, posts, sliding hardware, finish, and optional equipment as separate quoted items. Mark electrical work, foundations, installation, and operator commissioning as included or excluded. Confirm whether adjoining pedestrian gates need a matching finish or coordinated pattern.
Site delivery can be arranged under the agreed quotation. Provide truck access, receiving hours, and the unloading plan for long gate crates. Crane work, installation, duties, and accessories are not automatically part of a delivery price.
Send the survey and proposed equipment through Request a Quote. Use Order Samples for finish or pattern checks before approving the production drawing.
